E P I C B o a r d E P I C - Q M 5 7
Chapter 1 General Information 1- 4
1.3 Specifications
System
z
Form Factor EPIC Express Board
z
Processor Intel
®
Core™ i7/i5 Processor
(Socket-988)
z
System Memory 204-pin SODIMM DDR3 800/1066
Memory, up to 4GB, 8GB optional
z
Chipset Intel
®
QM57
z
I/O Chipset ITE8781
z
Ethernet 10/100/1000Base-TX x 2 (Intel
®
82577LM and Intel
®
82574L
respectively), RJ-45 x 2
z
BIOS AMI Plug & Play BIOS –
8MB Flash
z
Wake On LAN Yes
z
Watchdog Timer Generates a time-out system reset
z H/W
Status Monitoring Supports power supply voltages,
fan speed, and temperature
monitoring
z
Expansion Interface PCI/104-Express Expansion
(PCI-104 + PCIe/104 (Optional))
connector
z
Battery Lithium battery
z Power
Requirement +12V
