Page 34
E P I C B o a r d
E P I C - 5 5 3 6
Chapter 2 Quick Installation Guide
2-21
3 GND
4 +5V
2.35 Audio Line-in Connector (CN23)
Pin
Signal
1 LINE_IN_R
2 Audio
GND
3 LINE_IN_L
2.36 Battery Wafer (CN24)
Pin
Signal
1 Battery
Power
2 GND
2.37 CompactFlash Connector (CN25)
Standard Compact Flash Connector (Type I & II)
2.38 IDE Connector (CN26)
Pin Signal
Pin Signal
1 IDERST
2 GND
3 PID7
4 PID8
5 PID6
6 PID9
7 PID5
8 PID10
9 PID4
10
PID11
11 PID3
12 PID12
13 PID2
14 PID13
15 PID1
16 PID14
