E P I C B o a r d E P I C - 5 5 3 6
Chapter 2 Quick Installation Guide 2-12
2.12 TTL Clock and LVDS Operating Selection (JP6)
JP6 Function
3-5 Inverse Clock
1-3 Normal Clock (Default)
4-6 +3.3V for CN9 (Default)
2-4 +5V for CN9
2.13 Fan Power Selection (JP7)
JP7 Function
2-3 +5V
1-2 +12V (Default)
2.14 AT/ATX Power Type Selection (JP8)
JP8 Function
2-3 AT (Default)
1-2 ATX
2.15 LCD Backlight Control (JP9)
JP9 Function
2-3 +3.3V Level (Default)
1-2 +5V Level
2.16 DDR SODIMM Connector (CN1)
Standard DDR SODIMM Connector
