610.44520.40.000

12 / 52

© Gardner Denver Deutschland GmbH

Technical data

2.1.3 Temperature

increase

The information listed in the following tables
corresponds to the heating of the side channel
housing and the air exiting compared to the
ambient temperature during operation with a
permissible total pressure difference and an air
pressure of 1013 mbar [14.7 psi]. At lower air
pressures these values increase.

Temperature increase for

operation with output

frequency (approx.)

50 Hz

60 Hz

86 Hz

Type

∆T

[K]

∆υ

[F]

∆T

[K]

∆υ

[F]

∆T

[K]

∆υ

[F]

Single−impeller design
2BH7210−0.N1 52

126

61 142

2BH7210−0.N5 52

126

77 171

2BH7310−0.N2 81

178

86 187

2BH7310−0.N6 88

190

112

234

2BH7410−0.N1 90

194

101

214

2BH7410−0.N5 114

237

120 248

2BH7510−0.N2 120

248

112 243

2BH7510−0.N6 120

248

120 248

2BH7610−0.N3 118

244

124 255

120

248

Two−impeller design
2BH7220−0.N5 55

131

86

186

2BH7320−0.N5 81

178

124

255

2BH7320−0.N8 120

248

120

248

2BH7420−0.N2 89

192

80

176

2BH7420−0.N5 121

250

117

243

2BH7520−0.N7 125

257

110

230

2BH7620−0.N3 124

255

126

259

2BH7620−0.N4 124

255

126

259

120

248

Three-impeller design
2BH7630−0.N6 120

248

120

248 ≤

120

248

Tightening torques for screw connections

The following values apply if no other data are
given.
With non−electrical connections, property classes
of 8.8 and 8 or higher as per DIN ISO 898 (DIN
EN 20898 / DIN ISO 898) are assumed.

Tightening torques for

non−electrical connections

Thread

[Nm]

[lb-in]

M4

2,7 … 3,3

23,9 … 29,2

M5

3,6 … 4,4

31,9 … 38,9

M6

7,2 … 8,8

63,7 … 77,9

M8

21,6 … 26,4

191 … 234

M10

37,8 … 46,2

335 … 409

M12

63,0 … 77,0

558 … 681

Tightening torques for cable

and conduit glands Metal

Thread

[Nm]

[lb-in]

M12x1,5

4,0 … 6,0

35,4 … 53,1

M16x1,5

5,0 … 7,5

44,3 … 66,4

M20x1,5

6,0 … 9,0

53,1 … 79,7

M32x1,5
M40x1,5

8,0 … 12,0

70,8 … 106

Tightening torques for cable

and conduit glands Plastic

Thread

[Nm]

[lb-in]

M12x1,5

2,0 … 3,5

17,7 … 31,0

M16x1,5

3,0 … 4,0

26,6 … 35,4

M20x1,5

4,0 … 5,0

35,4 … 44,3

M32x1,5
M40x1,5

5,0 … 7,0

44,3 … 62,0

2.2 Electrical

data

See rating plate.
