Elmo Rietschle V-DTE 3/6/8/10 User Manual
Page 12
12
|
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
Set up and operation
B
A
E
P
1
N
F
F
A
D
B
O
Q
b
4
Set up and operation
4.1 Setup
Fig. 1 V-DTE compressor
A
Inlet silencer
B Pressure
connection
D
Pressure limitation valve
E
Cooling air inlet
F
Cooling air outlet
N Data
plate
O
Rotation direction arrow
P
1
Motor data plate
Q
hot surfaces > 70°C
b Housing
cover
