OM−00615 10 SERIES
MAINTENANCE & REPAIR PAGE E − 3
PARTS LIST
Pump Model 11 1/2A52−B
(From S/N 1241127 up)
If your pump serial number is followed by an N", your pump is NOT a standard production model. Contact
the Gorman-Rupp Company to verify part numbers.
1 PUMP CASING 12367 10010 1
2 IMPELLER 12368 10010 1
3 SEAL ASSY 25285−853 −−− 1
4 PIPE PLUG P04 15079 1
5 FILL PLUG ASSY 48271−066 −−− 1
6 NAME PLATE 38818−021 13990 1
7 DRIVE SCREW BM#04−03 17000 4
8 WARNING PLATE 2613EV 13990 1
9 DRIVE SCREW BM#04−03 17000 4
10 STUD C0607 15991 4
11 HEX NUT D06 15991 4
12 SLINGER RING 3228 19120 1
13 RETAINING RING S240 −−− 1
14 BALL BEARING S1085 −−− 1
15 VENTED PLUG 4823 15079 1
16 BALL BEARING S1085 −−− 1
17 RETAINING RING S240 −−− 1
18 BEARING SHIM SET 8540 15990 1
19 SHAFT KEY N0307 15990 1
20 IMPELLER SHAFT 2931 15000 1
21 SPRING RETAINER 31161−041 17000 1
22 IMPELLER ADJ SHIM SET 513A 17090 1
23 SHAFT SLEEVE 2353 17020 1
24 PEDESTAL 2928 10010 1
25 SEAL PLATE 2930A 10010 1
26 PUMP CASING GSKT SET 504GA 20000 1
27 WEAR PLATE ASSY 2643 15990 1
28 HEX NUT D04 15991 2
29 LOCKWASHER J04 15991 2
30 PIPE PLUG P06 15079 1
31 BACK COVER GASKET 12369G 20000 1
32 CLAMP BAR SCREW 8618 24000 1
33 COVER PLATE 12369 10010 1
34 HEX HD CAPSCREW B0808 15991 2
35 CLAMP BAR 12370 11010 1
36 STUD C0606 15991 4
37 HEX NUT D06 15991 4
38 SUCTION FLANGE 8599 10010 1
39 FLAP VALVE ASSY 1352 −−− 1
40 −RD HD MACH SCREW X0403 17090 1
41 −LOCKWASHER J04 17090 1
42 −SMALL VALVE WEIGHT 1354 15160 1
43 −FLAP VALVE/GSKT 1352G 19070 1
44 −LARGE VALVE WEIGHT 1353 10010 1
NOT SHOWN:
SUCTION STICKER 6588AG −−− 1
DISCHARGE STICKER 6588BJ −−− 1
PRIMING STICKER 6588AH −−− 1
ROTATION DECAL 2613M −−− 1
G-R DECAL GR03 −−− 1
INSTRUCTION LABEL 2613DK −−− 1
LUBE DECAL 38816−075 −−− 1
INSTRUCTION TAG 38817−010 −−− 1
INSTRUCTION TAG 38817−011 −−− 1
OPTIONAL:
HI TEMP SHUT DOWN KITS:
−120
_F 48313−257 −−− 1
−130 _F 48313−256 −−− 1
−145 _F 48313−186 −−− 1
HI TEMP SHUT DOWN THERMOSTAT KIT
− 145
_F 48313−172 −−− 1
JOHN CRANE MECH SEAL25271−846 −−− 1
STRAINER 12383 24000 1
INDICATES PARTS RECOMMENDED FOR STOCK
