ITEM
NO. PART NAME PART
NUMBER MAT'L
CODE QTY ITEM
NO. PART NAME PART
NUMBER MAT'L
CODE QTY
10 SERIES OM-00633
MAINTENANCE & REPAIR PAGE E - 3
PARTS LIST
Pump Model 13A22-B
(From S/N 1063371 Up)
If your pump serial number is followed by an “N”, your pump is NOT a standard production model. Contact
the Gorman‐Rupp Company to verify part numbers.
. 1 PUMP CASING SEE NOTE BELOW
2 IMPELLER 2996K 17070 1
3 SEAL ASSEMBLY 46512-157 ----- 1
4 DISCH FLANGE GSKT 1674GC 19410 1
5 DISCHARGE STICKER 6588BJ ----- 1
6 DISCHARGE FLANGE 1753A 17070 1
. 7 ACCESSORY PLUG P04 17090 1
8 HEX HD CAPSCREW B1007 17090 4
9 LOCKWASHER J10 17090 4
.10 FILL PLUG ASSEMBLY 48271-098 ----- 1
11 PRIMING DECAL 6588AH ----- 1
12 IMPELLER SHIM SET 2X 17090 REF
13 BOTTLE OILER S1933 ----- 1
14 PIPE COUPLING AE02 15079 1
15 PIPE NIPPLE T0208 15079 1
16 OIL SEAL S506 ----- 1
17 SHAFT SLEEVE 12449 1706H 1
18 SLINGER RING 3272 19120 1
19 OIL SEAL 25227-311 ----- 1
20 BALL BEARING 23275-008 ----- 1
21 PEDESTAL AIR VENT S1703 ----- 1
22 PEDESTAL 3114B 10010 1
23 ROTATION DECAL 2613M ----- 1
24 BALL BEARING 23275-008 ----- 1
25 BRG RETAINER O‐RING 25152-235 ----- 1
26 BRG RETAINING RING S247 ----- 1
27 OIL SEAL 25227-303 ----- 1
28 ALLEN HD SETSCREW GA#10-01S 15990 2
29 SHAFT KEY N0410 15990 1
30 IMPELLER SHAFT 38514-549 1706H 1
31 BEARING SHIM SET 48261-009 ----- 1
32 BEARING RETAINER 38322-521 26000 1
33 OIL LEVEL SIGHT GAUGE 26714-011 ----- 1
34 PIPE PLUG P06 15079 1
35 PEDESTAL DRAIN PLUG P06 15079 1
36 SEAL DRAIN PLUG P02 17090 1
.37 STUD C0607 17090 8
38 HEX NUT D06 17090 8
39 SEAL PLATE 38272-357 17070 1
40 CASING GSKT SET 3GD 19410 1
41 IMPELLER WASHER 10474 17090 1
42 IMPELLER CAPSCREW DM0603 17090 1
43 WEAR PLATE ASSY 2634C 17090 1
44 LOCKWASHER J06 17090 2
45 HEX NUT D06 17090 2
.46 CASING DRAIN PLUG P08 17090 1
47 COVER PLATE GSKT 2985GA 19410 1
48 COVER PLATE ASSY 42111-922 ----- 1
49 -DRAIN PLUG P04 17090 1
50 -COVER PLATE NOT AVAILABLE 1
51 -WARNING PLATE 2613EV 17090 1
52 -DRIVE SCREW BM#04-03 17000 4
53 COVER CLAMP SCREW 2536 24000 1
54 COVER CLAMP BAR 2987 11010 1
55 NAME PLATE 38818-023 17010 1
56 DRIVE SCREW BM#04-03 17000 4
57 STUD C0808 17090 4
58 HEX NUT D08 17090 4
59 CHECK VALVE ASSY 9845C ----- 1
60 -VALVE WEIGHT 9844 17090 1
61 -CHECK VALVE GSKT 9843G 19540 1
62 -VALVE WEIGHT 9843 17190 1
63 -RD HD MACH SCREW X0503 17090 1
64 -LOCKWASHER J05 17090 1
65 PIPE PLUG P04 17090 1
66 SUCTION FLANGE 2943 17070 1
67 CHECK VALVE GSKT 9842G 19410 1
68 CHECK VALVE SEAT 9842 17190 1
69 CHECK VALVE GSKT 9842G 19410 1
70 SUCTION STICKER 6588AG ----- 1
NOT SHOWN:
INSTRUCTION LABEL 2613DK ----- 1
LUBE DECAL 38816-079 ----- 1
OPTIONAL:
CASING HEATER:
-120V
47811-044 ----- 1
-240V 47811-045 ----- 1
HI TEMP SHUT-DOWN KITS:
-145
_ F 48313-186 ----- 1
-130 _ F 48313-256 ----- 1
-120 _ F 48313-257 ----- 1
INDICATES PARTS RECOMMENDED FOR STOCK
. INCLUDED WITH 46471-509 --- 1
REPAIR PUMP CASING ASSY
