Gorman-Rupp Pumps 810A2-F6L All serial numbers - Manual (Page 22)

ITEM
NO. PART NAME PART
NUMBER MAT’L
CODE QTY ITEM
NO. PART NAME PART
NUMBER MAT’L
CODE QTY
80 SERIES OM−02754
MAINTENANCE & REPAIR PAGE E − 3
PARTS LIST
Pump Model 810A2−F6L
(From S/N 1479254 Up)
If your pump serial number is followed by an N", your pump is NOT a standard production model. Contact
the Gorman-Rupp Company to verify part numbers.
1 PUMP END ASSY 810A2−(F6L) −−− 1
2 EXHAUST ELBOW 31912−036 15210 1
3 WEATHER CAP S1387 −−− 1
4 CONTROL PANEL KIT 48122−526 −−− 1
5 HOISTING BAIL 13351BB 24000 1
6 4’ FUEL RETURN LINE 18513−302 −−− 1
7 HOSE CLAMP 26518−642 −−− 2
8 MALE CONNECTOR 26523−333 −−− 2
9 REDUCER ELBOW R04 11999 1
10 FUEL RETURN LINE 14294 24030 1
11 MUFFLER GUARD ASSY 42331−035 −−− 1
12 DEUTZ F6L ENGINE 29217−361 −−− 1
13 CAUTION DECAL 2613FJ −−− 1
14 POS BATTERY CABLE 47311−114 −−− 1
15 BATTERY BOX ASSY GRP40−08C −−− 1
16 −HEX HD CAPSCREW B0607 15991 2
17 −FLAT WASHER KE06 15991 2
18 −FLANGED HEX NUT 21765−314 −−− 2
19 −BATTERY BOX LID 42113−012 24150 1
20 −GROUND CABLE ASSY 47311−064 −−− 1
21 −12V BATTERY SEE OPTIONS LIST REF
22 −BATTERY TAG 38818−506 −−− 1
23 −BATTERY BOX 42431−030 24150 1
24 −FLANGED HEX NUT 21765−314 −−− 8
25 −T TYPE LOCKWASHER BL06 15991 1
26 −STUD MOUNT 24631−006 −−− 4
27 HEX HD CAPSCREW B0604 15991 10
28 FLAT WASHER K06 15991 10
29 FLANGED HEX NUT 21765−314 −−− 10
30 FUEL TANK/GRD ASSY 46711−041 −−− 1
31 −FLAT WASHER K06 15991 6
32 −CARRIAGE BOLT AB0604 15991 6
33 −FLANGED HEX NUT 21765−314 −−− 6
34 −FUEL TANK 46711−042 24150 1
35 −TANK GUARD ASSY 34851−178 15080 1
36 HEX HD CAPSCREW B0816 15991 2
37 FLAT WASHER K08 15991 2
38 LOCKWASHER J08 15991 2
39 HEX NUT D08 15991 2
40 HOSE INLET ASSY 46341−803 −−− 1
41 MALE CONNECTOR S1447 −−− 1
42 HEX HD CAPSCREW B1006 15991 8
43 LOCKWASHER J10 15991 8
44 HEX NUT D10 15991 8
45 HEX HD CAPSCREW B0816 15991 2
46 FLAT WASHER K08 15991 2
47 LOCKWASHER J08 15991 2
48 HEX NUT D08 15991 2
49 COMBINATION BASE 41566−687 24150 1
50 HEX HD CAPSCREW B1209 15991 2
51 LOCKWASHER J12 15991 2
52 HEX NUT D12 15991 2
NOT SHOWN:
WARNING DECAL 2613FE −−− 1
ENGINE START-UP TAG 38816−269 −−− 1
STRAINER 3756 −−− 1
OPTIONAL:
12V BATTERY 29331−506 −−− 1
WHEEL KIT GRP30−248F −−− 1
TRAILER JACK 29313−146 −−− 1
REPAIR MUFFLER
GUARD ASSY
42331−050 −−− 1
INDICATES PARTS RECOMMENDED FOR STOCK
