OM-06018 ULTRA V SERIES
MAINTENANCE & REPAIR PAGE E - 9
PARTS LIST
Repair Rotating Assemblies
Note: Order the complete Repair Rotating Assembly from the Pump Model Assembly Parts Lists on pages
E-2 or E-3. Rotating Assemblies for /WW models also include all standard parts listed below.
1 IMPELLER 38615-107 11010 1
2 IMP ADJ SHIM SET 37J 17090 REF
3 CARTRIDGE SEAL ASSY 46513-151 --- 1
4 SEAL PLATE 38272-234 10010 1
5 GASKET 10959G 20000 1
6 OIL SEAL S1352 --- 3
7 BEARING HOUSING 38251-411 10000 1
8 LOCK WASHER J08 15991 4
9 HEX HD CAPSCREW B0805-1/2 15991 4
10 VENTED PIPE PLUG 4823A 15079 1
11 RED PIPE BUSHING AP0802 15079 1
12 AIR VENT S1530 --- 1
13 PIPE PLUG P12 15079 1
14 SIGHT GAUGE S1471 --- 2
15 PIPE PLUG P04 15079 2
16 HEX HD CAPSCREW B0605 --- 4
17 LOCK WASHER J06 15991 4
18 BEARING CAP 38322-220 10000 1
19 GASKET 38683-271 --- 1
20 RETAINING RING S442 --- 1
21 BALL BEARING S375 --- 1
22 SHAFT KEY N0608 15990 1
23 IMPELLER SHAFT 38514-817 16040 1
24 BALL BEARING S1088 --- 1
25 O‐RING 25154-022 --- REF
26 IMPELLER WASHER 31167-029 1706H 1
27 IMPELLER SCREW F1004S 17040 1
28 DRIVE SCREW BM#04-03 17000 2
29 S/N PLATE 2613GG 13990 1
30 O‐RING 25152-273 --- 1
31 O‐RING S1674 --- 1
32 SHIPPING PLUG 11495B 15079 2
33 SPACER 33221-022 17040 4
NOT SHOWN:
SOC HD PIPE PLUG PC20 10009 1
INSTRUCTION TAG 6588U --- 1
ROTATION DECAL 2613M --- 1
OPTIONAL:
TC CART SEAL ASSY 46513-150 --- 1
G‐R HARD IRON PARTS:
-IMPELLER
38615-103 1102H 1
-SEAL PLATE 38272-267 1102H 1
SST PARTS:
-IMPELLER
38615-107 17070 1
-SEAL PLATE 38272-234 17070 1
-IMPELLER SHAFT 38514-817 1706H 1
-CART SEAL ASSY 46513-156 --- 1
INDICATES PARTS RECOMMENDED FOR STOCK
