OM-06018
ULTRA V SERIES
MAINTENANCE & REPAIR
PAGE E - 5
PARTS LIST
46146-055 and 46146-132 Pump Assemblies
1
PUMP CASING
38224-614
10000
1
2
REPAIR ROTATING ASSY
VS3B60-B
44163-472
---
1
VS3B60-B /WW
44163-473
---
1
3
STUD
C1213
1500G
4
4
PIPE PLUG
P20
10009
1
5
WEAR PLATE ASSY
46451-760
24150
1
6
O‐RING
25152-273
---
1
7
LOCK WASHER
J06
15991
4
8
HEX NUT
D06
15991
4
9
O‐RING
S1674
---
2
10
COVER PLATE ASSY
42111-831
---
1
-WARNING PLATE
2613EV
13990
1
-DRIVE SCREW
BM#04-03
17000
4
-PRESS RELIEF VALVE
26662-007
---
1
-WARNING DECAL
38816-302
---
1
11
LOCK COLLAR
38115-551
23030
4
12
LOCK WASHER
J08
15991
8
13
ADJUSTING SCREW
31871-070
1500G
4
14
HEX HD CAPSCREW
B0804
15991
4
15
BACK COVER NUT
31871-073
15000
4
16
HEX HD CAPSCREW
B0604-1/2
15991
2
17
HANDLE
12354
13010
1
18
HEX HD CAPSCREW
VS3B60-B
B1009
15991
8
VS3B60-B /WW
B1013
15991
8
19
LOCK WASHER
J10
15991
8
20
PIPE PLUG
P04
15079
3
21
NPT SUCT FLG/VLV SEAT 38641-534
10000
1
22
GASKET
38683-502
19370
1
23
ROLL PIN
21154-229
---
2
24
FLAP VALVE PLUG
38349-416
19020
1
25
FLAP VALVE COVER
38346-621
17040
1
26
LOCK WASHER
J05
15991
4
27
HEX HD CAPSCREW
B0504
15991
6
28
SQUARE HD BOLT
A1014
15991
2
29
FILL PORT COVER ASSY
42111-437
---
1
-FILL PORT GASKET
50G
19210
1
-WARNING PLATE
38816-097
13990
1
-DRIVE SCREW
BM#04-03
17000
2
30
CLAMP BAR
38111-004
11010
1
31
HEX HD CAPSCREW
B1010S
15991
1
32
HEX HD CAPSCREW
B0805-1/2
15991
4
33
SPACER
33221-022
17040
4
34
PIPE PLUG
P08
15079
2
NOT SHOWN:
SUCTION SPOOL PARTS (VS3B60-B /WW ONLY)
-SPOOL FLANGE
12066A
10010
1
-FLANGE GASKET
25113-034
---
1
-FLANGE PIPE PLUG P20
10009
1
OPTIONAL:
DISASSEMBLY TOOL
48711-020
---
1
FLANGE KITS:
3” NPT DISCH KIT
48213-119
---
1
4” X 3” ASA SUCTION/DISCHARGE
SPOOL KIT
48213-143
---
1
-4” ASA SUCTION
SPOOL KIT
48213-142
---
1
-3” ASA DISCHARGE
SPOOL KIT
48213-120
---
1
4” X 3” METRIC SUCTION/DISCHARGE
SPOOL KIT
48213-121
---
1
-4” METRIC SUCTION
SPOOL KIT
48213-144
---
1
-3” METRIC DISCHARGE
SPOOL KIT
48213-145
---
1
G‐R HARD IRON PARTS:
-WEAR PLATE ASSY
46451-758
24150
1
SST PARTS:
-WEAR PLATE ASSY
46451-758
24170
1
HI TEMP SHUT-DOWN KITS:
-145
_F
48313-186
---
1
-130
_F
48313-256
---
1
-120
_F
48313-257
---
1
HIGH TEMP SHUT‐DOWN
THERMOSTAT KIT 145
_F 48313-172 ---
1
AIR RELEASE VALVES:
-10# COMP SPRING
GRP33-07A ---
1
-25# COMP SPRING
GRP33-07
---
1
-80# COMP SPRING
GRP33-07B ---
1
INDICATES PARTS RECOMMENDED FOR STOCK
