ITEM
NO. PART NAME PART
NUMBER MAT’L
CODE QTY ITEM
NO. PART NAME PART
NUMBER MAT’L
CODE QTY
ULTRA V SERIES OM−06289
MAINTENANCE & REPAIR PAGE E − 9
PARTS LIST
V4A60−(SAE 4/10) Pump End Assembly
1 PUMP CASING 38224−613 10000 1
2 REPAIR ROTATING ASSY 44163−490 −−− 1
3 STUD C1213 15991 4
4 PIPE PLUG P20 10009 1
5 WEAR PLATE ASSY 46451−760 24150 1
6 O-RING 25152−273 −−− 1
7 LOCK WASHER J06 15991 10
8 HEX NUT D06 15991 2
9 O-RING S1674 −−− 1
10 BACK CVR PLATE ASSY 42111−831 −−− 1
−WARNING PLATE 2613EV 13990 1
−DRIVE SCREW BM#04−03 17000 4
−PRESS RELIEF VALVE 26662−007 −−− 1
−WARNING DECAL 38816−302 −−− 1
11 LOCK WASHER J08 15991 8
12 HEX HD CAPSCREW B0804 15991 4
13 HEX HD CAPSCREW B0604−1/2 15991 2
14 HANDLE 12354 13010 1
15 BACK COVER NUT 31871−073 15000 4
16 LOCK COLLAR 38115−551 15010 4
17 ADJUSTING SCREW 31871−070 1500G 4
18 HEX HD CAPSCREW B1211 15991 8
19 LOCK WASHER J12 15991 8
20 PIPE PLUG P04 15079 2
21 SUCTION FLANGE 38641−532 10000 1
22 SUCT FLG GASKET 38683−660 19370 1
23 ROLL PIN 21154−229 −−− 2
24 FLAP VALVE ASSY 46411−151 24150 1
25 FLAP VALVE COVER 38346−619 17040 1
26 HEX HD CAPSCREW B0604 15991 6
27 SQUARE HD BOLT A1014 15991 2
28 FILL PORT COVER ASSY 42111−437 −−− 1
−FILL PORT GASKET 50G 19210 1
−WARNING PLATE 38816−097 13990 1
−DRIVE SCREW BM#04−03 17000 2
29 CLAMP BAR 38111−004 11010 1
30 HEX HD CAPSCREW B1010S 15991 1
31 4" ELBOW 38647−922 10010 1
32 HEX HD CAPSCREW B1007 15991 8
33 LOCK WASHER J10 15991 8
34 PIPE PLUG P16 10009 1
35 GASKET 25113−034 −−− 1
36 HEX HD CAPSCREW B0806 15991 4
37 COUPLING KIT 48112−013 −−− 1
38 SPACER 33221−022 17040 4
39 O-RING S1676 −−− 1
40 O-RING 25152−273 −−− 1
41 PIPE PLUG P08 15079 2
42 DRIVE SCREW BM#04−03 17000 4
43 NAME PLATE 38818−149 13000 1
NOT SHOWN:
4" STRAINER 7823A 24000 1
PRIMING STICKER 6588AH −−− 1
INSTRUCTION TAG 38817−085 −−− 1
SUCTION STICKER 6588AG −−− 1
WARNING DECAL 2613FE −−− 1
ULTRA V" DECAL 38816−342 −−− 1
LUBE DECAL 38817−084 −−− 1
DISCHARGE STICKER 6588BJ −−− 1
G-R DECAL GR−03 −−− 1
WARNING DECAL 38816−302 −−− 1
OPTIONAL:
DISASSEMBLY TOOL 48711−020 −−− 1
FLAP VALVES:
[ −FLUOROCARBON 46411−152 24010 1
−BUNA-N 46411−153 24010 1
−EPDM 46411−157 24010 1
FLANGE KITS:
4" NPT DISCH KIT
48213−125 −−− 1
6" X 4" ASA SUCTION/DISCHARGE
SPOOL KIT
48213−147 −−− 1
−6" ASA SUCTION
SPOOL KIT 48213−146 −−− 1
−4" ASA DISCHARGE
SPOOL KIT 48213−126 −−− 1
6" X 4" METRIC SUCTION/DISCHARGE
SPOOL KIT
48213−127 −−− 1
−6" METRIC SUCTION
SPOOL KIT 48213−148 −−− 1
−4" METRIC DISCHARGE
SPOOL KIT 48213−149 −−− 1
INDICATES PARTS RECOMMENDED FOR STOCK
[ DUPONT VITON R
OR EQUIVALENT
