ULTRA V SERIES OM−06289
MAINTENANCE & REPAIR PAGE E − 7
PARTS LIST
46143−093 Deutz D914L3 Power Unit
ITEM
NO.
PART NAME
PART
NUMBER MAT’L
CODE
QTY
1 DEUTZ F3L ENGINE 29217−221 −−− 1
2 BASE/FUEL TANK 41553−005 24150 1
3 MUFFLER GUARD ASSY 42331−029 −−− 1
4 POS BATTERY CABLE 47311−113 −−− 1
5 NEG BATTERY CABLE 47311−177 −−− 1
6 OIL DRAIN ASSY 46342−033 −−− 1
7 CONTROL PANEL KIT 48313−793 −−− 1
8 EXHAUST ELBOW 31912−038 15000 1
9 WEATHER CAP S1331 −−− 1
10 BATTERY BOX ASSY 42432−005 −−− 1
11 HEX HD CAPSCREW B1017 15991 2
12 LOCKWASHER J10 15991 2
13 HEX NUT D10 15991 2
14 3/8" ID x 30" LG. HOSE 18513−302 −−− 1
15 HOSE CLAMP 26518−642 −−− 2
16 HOSE BARB FITTING 26523−333 −−− 2
17 FLAT WASHER K10 15991 4
18 HEX HD CAPSCREW B1007 15991 8
19 FUEL GAUGE 29332−135 −−− 1
20 FUEL PICKUP 29332−145 −−− 2
21 HOSE ASSY 46341−796 −−− 1
22 MALE CONNECTOR S1447 −−− 1
23 R.H. ENGINE SIDE RAIL 34451−085 15080 1
24 L.H. ENGINE SIDE RAIL 34451−086 15080 1
25 LIFTING BAIL KIT 48274−801 −−− 1
NOT SHOWN:
ENGINE OPERATING DECAL 38816−347 −−− 1
ENGINE STARTUP TAG 38816−269 −−− 1
FLOAT SWITCH 48312−980 −−− 1
INSTRUCTION DECAL 38818−144 −−− 1
WARNING DECAL 38816−203 −−− 2
LOW SULFER FUEL DECAL 38816−196 −−− 1
WARNING DECAL 2613FE −−− 2
CAUTION DECAL 2613FJ −−− 1
WARNING DECAL 38816−345 −−− 1
OPTIONAL:
HEATED 30MIC ENGINE FUEL FILTER KIT 48122−914 −−− 1
DUAL FLOAT SWITCH KIT 48312−981 −−− 1
EPS W/TRANDUCER AUTOSTART CONTROL PANEL
48122−515 −−− 1
