OM−06301 PA SERIES
MAINTENANCE & REPAIR PAGE E − 19
PARTS LIST
44163−229 Repair Rotating Assembly
ITEM
NO.
PART NAME
PART
NUMBER MAT’L
CODE
QTY
1 IMPELLER 10528 11010 1
2 CARTRIDGE SEAL ASSY 46513−151 −−− 1
3 IMP ADJ SHIM SET 37J 17090 REF
4 SHAFT SLEEVE O-RING 25154−022 −−− REF
5 SEAL PLATE 38272−234 10010 1
6 SEAL PLATE GASKET 109959G 20000 1
7 HEX HD CAPSCREW B0805−1/2 15991 4
8 LOCK WASHER J08 15991 4
9 PIPE PLUG P12 15079 1
10 INTERMEDIATE GUARD 42381−509 24152 2
11 VENTED PIPE PLUG 4823A 15079 1
12 AIR VENT S1530 −−− 1
13 REDUCER PIPE BUSHING AP0802 15079 1
14 INTERMEDIATE BRACKET 38266−007 10000 1
15 HEX HD CAPSCREW B0605 15991 4
16 LOCK WASHER J06 15991 2
17 OIL SEAL S1352 −−− 2
18 BEARING CAP 38322−215 10010 1
19 SIGHT GAUGE S1471 −−− 1
20 BEARING CAP GASKET 38683−248 18000 1
21 SNAP RING S244 −−− 1
22 BALL BEARING S1040 −−− 1
23 SHAFT KEY N0610 15990 1
24 PIPE PLUG P08 15079 2
25 IMPELLER SHAFT 38514−561 1706H 1
26 BALL BEARING 23276−009 −−− 1
27 SEAL PLATE O-RING 25154−273 −−− 1
28 BEARING HOUSING O-RING S1674 −−− 1
29 BEARING HOUSING ADJ SHIM SET 13130 17040 4
30 SHIPPING PLUG 11495B 15079 2
NOT SHOWN:
INSTRUCTION TAG 6588U −−− 1
INDICATES PARTS RECOMMENDED FOR STOCK
