80 SERIES OM-05132
MAINTENANCE & REPAIR PAGE E - 5
PARTS LIST
82E1-(L100EE-X PPO)
ITEM
NO.
PART NAME
PART
NUMBER MAT'L
CODE
QTY
1 PUMP CASING 6851D 13040 1
2 IMPELLER 38614-036 13040 1
3 SEAL ASSY 25271-888 --- 1
4 DISCHARGE STICKER 6588BJ --- 1
5 STREET ELBOW RS32 11999 1
6 PUMP CASING GSKT SET 229G 20010 1
7 INTERMEDIATE BRKT 38264-224 10010 1
8 STUD C0606 15991 6
9 HEX NUT D06 15991 6
10 SHAFT SLEEVE 31413-092 16000 1
11 IMP ADJ SHIM SET 2X 17090 1
12 HEX HD CAPSCREW 22645-538 --- 4
13 LOCKWASHER 21171-510 --- 4
14 NAME PLATE 38818-019 13990 1
15 DRIVE SCREW BM#04-03 17000 4
16 WEAR PLATE ASSY 6822 15990 1
17 HEX NUT D06 15991 1
18 LOCKWASHER J06 15991 1
19 CASING DRAIN PLUG P12 15079 1
20 HEX HD CAPSCREW B0614 15991 1
21 FLAT FIBER WASHER KF06 18040 1
22 STUD C0606 15991 4
23 HEX NUT D06 15991 4
24 SUCTION FLANGE 1361 13040 1
25 CHECK VALVE ASSY 1361E --- 1
26 -RD HD MACH SCREW X0403 17090 1
27 -LOCKWASHER J04 17090 1
28 -SMALL VALVE WEIGHT 1354 15160 1
29 -CHECK VALVE GASKET 1361GC 19550 1
30 -LARGE VALVE WEIGHT 19B 10010 1
31 SUCTION STICKER 6588AG --- 1
32 FILL PLUG ASSY 48271-062 --- 1
33 PRIMING STICKER 6588AH --- 1
34 SPRING CENTERING WASHER 31512-049 17060 1
INDICATES PARTS RECOMMENDED FOR STOCK
