Installation, Operating and Maintenance Instruction
Model LS, LC, LCP
LS 100-english
page 8
Revision 02
Artikel No. 771073402
Issue
01/2010
3.3.2 Oil Sump Cooling
On temperatures of the pumped liquid over 180°C an
oil sump cooling is required.
For connection refer to list "Connections" in the annex.
For cooling use pure, non-aggressive water with a
maximum incoming temperature of 30°C.
Cooling water should be hand-warm at discharge.
The pressure in the cooling system must not
exceed max. 6 bar.
Provide control devices for temperature and
pressure monitoring.
3.4
Approximate
Value
for
Sound
Pressure Level
Nominal
power
P
N
in kW
Sound pressure level L
pA
in dB(A)
Pump alone
Pump + Motor
2950
rpm
1450
rpm
975
rpm
2950
rpm
1450
rpm
975
rpm
5,5
--
61,0
- -
- -
64,0
- -
7,5
--
63,0
- -
- -
64,5
- -
11,0
--
65,0
- -
- -
66,0
- -
15,0
--
66,5
- -
- -
67,5
- -
18,5
68,5
68,0
- -
69,0
69,0
- -
22,0
69,5
68,5
- -
70,0
69,5
- -
30,0
71,0
70,5
- -
71,5
71,0
- -
37,0
72,0
71,5
- -
73,0
72,0
- -
45,0
73,0
72,5
- -
74,0
73,5
- -
55,0
74,5
73,5
- -
75,0
74,5
- -
75,0
76,0
75,5
- -
76,5
76,5
- -
90,0
77,0
76,5
- -
77,5
77,5
- -
110,0
78,0
77,5
77,0
79,0
78,5
80,0
132,0
79,0
78,5
78,0
79,5
79,5
80,0
160,0
80,0
79,5
79,0
80,5
81,0
80,5
200,0
81,5
81,0
80,5
81,5
82,0
83,0
250,0
82,5
82,0
81,5
84,5
83,0
84,0
315,0
83,5
83,0
83,0
85,0
85,5
84,5
355,0
84,5
84,0
- -
85,5
86,0
- -
400,0
85,0
84,5
- -
88,0
86,5
- -
450,0
--
85,0
- -
- -
87,0
- -
500,0
--
85,5
- -
- -
87,0
- -
Sound pressure level L
pA
measured in 1 m distance
from pump surface acc. to DIN 45635, part 1 and 24.
Room and foundation influences are not considered.
The tolerance for these values is ±3 dB(A).
Addition with 60 Hz-operation:
Pump alone: −
Pump with motor: +4 dB(A)
3.5 Permitted Nozzle Loads and Torques
at the Pump Nozzles ...
... following the Europump-Recommendation for
pump acc. to ISO 5199.
The data for forces and torques are only valid for static
piping loads.
The values given in the chart are valid for pump units
with standard LS- or LCP-base frames (grouted).
The data for forces and torques refer to LC or LCP-
standard materials 0.7040 (ductil iron) and 1.4408
(stainless steel).
For the LS-standard material 0.6025 (cast iron) the
values must be multiplied with factor 0,5.
LS, LC
LCP
