TABLE 2: Flow Rates converted from Feet/Sec to Gallons/Minute at various velocities: Schedule 40 pipe
Nominal pipe size
Feet / Sec
▲
3" 4" 5" 6" 8" 10" 12" 16" 24" 36" 38" 40"
11.5 19.8 31.2 45 78 123 176 313 704 1585 1770 1960
23 39.7 62.4 90 156 246 349 551 1250 2910 3530 3915
46.1 79.4 125 180 312 492 698 1100 2510 5830 7070 7825
115 198 312 450 780 1230 1740 2750 6270 14570 17670 19560
230 397 624 900 1560 2460 3490 5510 12530 29140 35350 39120
461 794 1250 1800 3120 4920 6980 11020 25060 58270 70700 78240
691 1190 1870 2700 4680 7370 10470 16520 37600 87410 106050 117500
Flow Range. These sensors are designed to operate at flow
velocities of 0.5 to 30 feet per second (see Table 2, below).
If erratic readings are encountered at low flows, check the
chart to see if flow is below minimum for the pipe size. The
standard shaft and bearings should have a long life at continu-
ous high flow.
OPERATION
