7
8
9
11
10
13
12
3
7
6 5
4
2
1
Page 8
PARTS EXPLOSION
TX80-SERIES PARTS LISTING
Upper Housing
Gasket
Lower Housing
Housing Screw
Plug, Steel
Plug, Plastic
Strain Relief
Sensor Retaining Screw
Pick Up, Standard Low Power
or
Pick Up, Micro Power (FT415/DL76)
O-Ring, EPDM
or
O-Ring, Viton
Rotor Repair Kit
(Polypro/Tungsten Carbide)
Rotor Assembly
(Polypro/Tungsten Carbide)
U-Clip
1
2
3
4
5
6
7
8
9
10
11/12
12
13
26181
26211
29930
26229
26073
26079
07655
25321
26310
29953
25081
16455
33087
33015
15527
