Xylem WL200 CONDUCTIVITY LEVEL CONTROLLERS User Manual
Global water, Instrumentation, inc, Conductivity sensor head wl200
Table of contents
Document Outline
- Global Water
- Int’l: (916) 638-3429, F: (916) 638-3270
- Conductivity Sensor Head WL200
- I. WL200 Checklist
- II. Inspection
- a. Your WL200 unit was carefully inspected and certified by our Quality Assurance Team before shipping. If any damage has occurred during shipping, please notify Global Water Instrumentation, Inc. and file a claim with the carrier involved.
- b. Use the checklist to ensure that you have received everything needed to operate the WL200.
- III. Features
- a. Conductivity Switch
- 1. Sensitivity-adjustable controller
- 2. No moving parts
- 3. Safe operation
- 4. Controls up to two levels with controller
- 5. 1” NPT fitting (bulkhead or flange-type fitting available.)
- 6. One to three electrodes, depending upon tank material and number of functions required
- 7. Electrodes are 1/8” diameter, 316 Stainless Steel; all wetted material are food grade.
- 8. Standard 24” electrode can be cut by end user to shorten the length; two 24” extensions can be added for a maximum recommended length of 72”.
- 9. Option
- 10. Other
- b. R-Series Controller
- a. Conductivity Switch
- IV. Specifications
- V. Operation
- VI. Installation
- Warnings: Install controller according to applicable electrical codes.
- Unit must be installed using Global Water’s R2 Controller.
- Do not connect directly to line voltage.
- Not for use in hazardous (explosive) environments.
- Do not exceed pressure and temperature ratings.
- a. Conductivity Sensor Head / Conductivity Probes
- 1. 1 inch NPT (Standard)
- 2. Probes can be cut to length. Remove probes from sensor head by carefully unthreading them from inserts. Do not over tighten when reinstalling.
- 3. Cut two (2) probes to the same length, these will be the common and lower level probes. (See Figure 1, page 11.)
- 4. Cut one (1) probe to the desired length for the upper level of the tank. (See Figure 1, page 11.)
- 5. Spacer should be located approximately 1 inch from bottom of shortest probe.
- 6. If build up occurs on probes a short circuit could occur. If this happens, apply shrink tubing to the probes leaving the last one (1) inch bare.
- b. Wiring
- 1. Install cable into sensor head through the compression fitting supplied.
- 2. Attach one lead between the common probe terminal, and pin five (5) on the controller.
- 3. Attach a second lead between the lower level probe terminal, and pin six (6) on the controller.
- 4. Attach a third lead between the upper level probe terminal, and pin eight (8) on the controller.
- 5. Tighten compression fitting until cable can not be pushed into sensor head.
- c. R2 Conductivity Configuration:
- 1. 120 VAC is connected between pins 2 and 7
- 2. Wire the Common Probe to pin 5
- 3. Wire the Lower Probe to pin 6
- 4. Wire the Upper Probe to pin 8
- 5. Pins 1–3 and 1–4 are isolated switch contacts to switch power to a valve or pump.
- Note: For single level control, connect probe to pin 8 and use pin 5 as the return
- d. Typical Controller Hookup to Switches:
- 1. Set switches “Normally Open.”
- 2. Connect Upper switch to pins 6 and 8, Lower switch to pins 5 and 6.
- 3. Connect the switched voltage to terminal 1 (AC or DC Volts)
- 4. For Pump-Up: Connect one end of the pump/valve to terminal 4 and the other end to the switched voltage return
- 5. For Pump-Down: Connect one end of the pump/valve to terminal 3 and the other end to the switched voltage return.
- 6. Connect line voltage to terminals 2 and 7.
- e. Conductivity Probe Kit Add-On Electrode Installation:
- 1. Cut the add-on electrodes to the length needed for your application. De-burr the cut ends with a fine file or equal.
- 2. Insert the threaded end of each add-on electrode into a coupling, just to the end of the threads.
- 3. Secure the coupling to the electrode with one (1) of the supplied set screws.
- 4. Connect the add-on electrodes to the electrodes from the junction box by placing the couplings over the electrode ends until the ends of the add-on electrodes contact the junction box electrodes.
- 5. Secure the couplings to the electrodes with the rest of the supplied set screws.
- 6. Slide the plastic spacer from the kit over the ends of the extended electrodes. (See Figure 2, page 11.)
- VII. Maintenance
- VIII. Trouble Shooting
- a. Call us for tech support: 800-876-1172 or 916-638-3429 (many problems can be solved over the phone). Fax: 916-638-3270 or Email: [email protected]. Be prepared to describe the problem you are experiencing including specific details of the application and installation and any additional pertinent information.
- b. In the event that the equipment needs to be returned to the factory for any reason, please call to obtain an RMA# (Return Material authorization). Do not return items without an RMA# displayed on the outside of the package. Clean and decontaminate the WL200 if necessary. Include a written statement describing the problems. Send the package with shipping prepaid to our factory address. Insure your shipment, as the warranty does not cover damage incurred during transit.
- c. When calling for tech support, please have the following information ready:
- IX. Warranty
- a. Global Water Instrumentation, Inc. warrants that its products are free from defects in material and workmanship under normal use and service for a period of one year from date of shipment from factory. Global Water’s obligations under this warranty are limited to, at Global Water’s option: (I) replacing or (II) repairing; any products determined to be defective. In no case shall Global Water’s liability exceed the products original purchase price. This warranty does not apply to any equipment that has been repaired or altered, except by Global Water Instrumentation, Inc., or which has been subject to misuse, negligence or accident. It is expressly agreed that this warranty will be in lieu of all warranties of fitness and in lieu of the warranty of merchantability.
- b. The warranty begins on the date of your invoice.
