Xylem WA400 HIGH WATER ALARM User Manual
Page 6
Global Water
800-876-1172
• globalw.com
- 6 -
VI.
High Water Alarm Installation
a. Slowly remove top cap to access power compartment and
Input/Output terminals. Be careful not to snag or break any wires of
the sensors or alarm.
(DC, FS) models will have battery terminals.
(AC, AL) Models will not have battery terminals.
Power connected directly to the board.
Note: (BU) Model will have both Battery compartment and Power
wires from an AC-DC converter.
Speaker wires
Speaker wires
Power
(from AC-DC converter)
