XL™ SERIES
XL-BASIC Programming Guide 23-19
PC Menu Screen: XL-Basic Options.
XL-BASIC Code Options (Esc to Return)
L - Load Code: From PC Card to Memory:
G - Get Code: From Memory to PC Card:
Pgm Number Pgm Name Pgm Value
1 - Test XL-Basic1: TMEAS 0.000
2 - Test XL-Basic2: STG_AVG 0.000
3 - Test XL-Basic3: 0.000
4 - Test XL-Basic4: 0.000
5 - Test XL-Basic5: 0.000
S - Single Step Mode: Disabled
Enter Option >_
PC Interface View Built In Display Screen
L - Load Code: From PC Card to Memory Load XL-Basic Code?
This menu option is used to load XL-BASIC code. Not all five programs have to be loaded.
When this option is activated the system performs the following tasks:
1 - Make sure an external PC card is installed and functional.
2 - Erase all XL-BASIC programs currently loaded into internal memory.
3 - The data logger prompts the user to select a file to load for XL-BASIC program 1.
4 - Using the UP, DOWN, and ENTER key the user selects a file to load.
5 - The data logger prompts for files 2, 3, 4, and 5 in the same manner until all are loaded.
PC Interface View Built In Display Screen
G - Get Code: From Memory to PC Card Get XL-Basic Code?
This menu option is used to get XL-BASIC code out of the XL back onto a data card. When this
option is used the system looks for an external data card and copies the XL-BASIC programs in
main memory to the external data card.
PC Interface View Built In Display Screen
1 - Test XL-Basic 1: Name XX.XX XL-BASIC1 = XX.XX
This menu option is used to execute the different programs. When the program finishes running
any value associated to the program will be updated and redisplayed. Remember there is a
