Appendix A
Specifications
H-340
Appendix A Specifications A-1
General
Resolution: 0.01 Inches (@4in/hr)
Rate: 0 to 25 inches/hour
Calibrated @ 8.237 mL/tip = 0.01in rainfall,
includes computer printout of conformance.
Magnetic Reed Switch
Type: Normally open
encapsulated reed.
Rating: 200VDC max
0.1A max
Contact Resistance: 0.2 ohms
Output Connection
2-position screw barrier strip
Environmental
Operating Temperature: -0 to 60 C
Mechanical
Aperture: 8 inch diameter funnel
Diameter: 8 inches
Height: 12 inches
Weight: 8 pounds
Housing:
Extruded aluminum tube. Cast aluminum base.
Anodized aluminum internal parts. Stainless steel
screws and fasteners. Powder painted base, funnel
and housing.
Mounting: 3-stainless leveling screws with
adjustable aluminum feet. Internal
“bulls-eye”level.
Exit Ports: Two screened drain tube fittings on
bottom of casting.
Warranty
The W ATER LOG ® H-340 is warranted against
defects in materials and workmanship for one year
from date of shipment.
