Xylem ECOCIRC EB EBV IM User Manual
Page 36
es
36
10.
Fin de vida útil y gestión de residuos
Este producto así como sus piezas han de ser tratados al final de su vida útil de acuerdo
con las directrices locales vigentes que regulan la gestión de residuos y la protección del
medio ambiente.
11. Diagrama
de
despiece
(véase figura 9)
1. Estator/Motor de la bomba
2. Tuerca de racor
3. Cojinete de cerámica
4. Junta
5. Rotor / Rodete
6. Carcasa de la bomba
7. Rosca de conexión
8. Válvula de retención RV ½“ en EB…./65, incluida en el volumen de suministro
9. Válvula esférica de cierre integrada con palanca de manejo
10. Válvula de retención integrada
