SVI PRODUCT LINE NUMBERING SYSTEM
ComPlETE PUmPS
2 SV N 1 G 11 F H E 5 EXAmPlE PRoDUCT CoDE*
Seal options:
0 = Standard Silicon Carbide/Carbon/Viton
4 = Silicon Carbide/Silicon Carbide/Viton
5 = Tungsten Carbide/Tungsten Carbide/Viton
Discharge Connection:
E = NPT M = BSP A = Flanged ANSI Drilling D = Flanged DIN Drilling
Bowls:
A = 1 E = 5 J = 9 N = 13
B = 2 F = 6 K = 10 P = 14
C = 3 G = 7 L = 11 Q = 15
D = 4 H = 8 M = 12 R = 16
Impellers:
A = 1 E = 5 J = 9 N = 13
B = 2 F = 6 K = 10 P = 14
C = 3 G = 7 L = 11 Q = 15
D = 4 H = 8 M = 12 R = 16
Driver:
01 = 1PH, ODP, NEMA 07 = 3PH, XP, NEMA 13 = 3PH, 575V, TEFC, NEMA, MF**
02 = 3PH, ODP, NEMA 08 = 575V, XP, NEMA 14 = 1PH, 230V, TEFC, NEMA, MF**
03 = 575V, ODP, NEMA 09 = 3PH, TEFC, PE, NEMA 15 = 3PH, 220-255/380-440, IEC
04 = 1PH, TEFC, NEMA 10 = 1PH, XP, NEMA 16 = 3PH, 265-277/460-480, IEC
05 = 3PH, TEFC, NEMA 11 = 3PH, 200V, TE, NEMA, MF**
06 = 575V, TEFC, NEMA 12 = 3PH, 208-230/460V, TE, NEMA, MF**
**MF = Metric Flange
HP Rating:
C =
½
F = 1½ J = 5 M = 15 Q = 30
D = ¾ G = 2 K = 7½ N = 20
E = 1 H = 3 L = 10 P = 25
Hertz/RPm:
1 = 60 Hz/3500 RPM
2 = 50 Hz/2900 RPM
Version:
S = CI/NEMA Motor Adapter
X = CI/IEC Motor Adapter
N = Stainless Steel/IEC Motor Adapter
Product line: Stainless Vertical Immersed
Nominal Flow:
1 = 15 GPM 3 = 55 GPM
2 = 28 GPM 4 = 86 GPM
* Not all combinations are available.
➤
