INTERPRETINg mOdEl NUmbERs
The model number of the FloStandard appears on the shipping carton label and on the technical data
label affixed to the panel. The information provided by the model number is shown below:
FloStandard™ Simplex Pump Control Panels J
Units supplied with Class 0 adjustable Overload Protection (For Above Ground Pumps)
NEMA
Max. Fuse
Order Max. Input
Starter
Max. holder Enclosure Weight
Number HP Voltage
Size
Amps Size Size lbs.
(Amps) ‡
FV2070027A1 7½ 1 27 30
36”H x 16”W x 9”D
40
FV2015045A2 15 2 45 60 55
FV2030090A3 30 230 3 90 100
45”H x 20”W x 11”D
111
FV2050130A4 50 4 135 200 170
FV2100311A5 100 5 270 400 73”H x 22”W x 18”D 440
FV4010018B1 10 1 27 30
36”H x 16”W x 9”D
40
FV4025045B2 25 2 45 60 55
FV4050090B3 50 460 3 90 100
45”H x 20”W x 11”D
111
FV4100200B4 100 4 135 200 170
FV4200311B5 200 5 270 400 73”H x 22”W x 18”D 440
‡Class J fuses are not supplied.
Units supplied with Class 10 Overload Protection (For Submersible Pumps)
NEMA
Max. Fuse
Order Max. Input
Starter
Max. holder Enclosure Weight
Number HP Voltage
Size
Amps Size Size lbs.
(Amps) ‡
FV2070027A1T 7½ 1 27 30
36”H x 16”W x 9”D
40
FV2015045A2T 15 2 45 60 55
FV2030090A3T 30 230 3 90 100
45”H x 20”W x 11”D
111
FV2050130A4T 50 4 135 200 170
FV2100311A5T 100 5 270 400 73”H x 22”W x 18”D 440
FV4010018B1T 10 1 27 30
36”H x 16”W x 9”D
40
FV4025045B2T 25 2 45 60 55
FV4050090B3T 50 460 3 90 100
45”H x 20”W x 11”D
111
FV4100200B4T 100 4 135 200 170
FV4200311B5T 200 5 270 400 73”H x 22”W x 18”D 440
‡Class J fuses are not supplied.
