AquaBoost Controller Drive Head Technical Data

AquaBoost

Supply

Motor

Voltage

Controller

Protection

Type Rated

output

Voltage

AV 1.1

1 HP

1 x 230 V / 40-60 Hz

3 x 230 V

4.8 A

10 Ampere

AV 1.15

2 HP

1 x 230 V / 40-60 Hz

3 x 230 V

7.0 A

10 Ampere

AV 1.2

3 HP

1 x 230 V / 40-60 Hz

3 x 230 V

10.0 A

16 Ampere

Input Voltage:

1 x 230 VAC ± 10% (An input line reactor is highly recommended

for areas which experience voltage ﬂ uctuation.)

Output Voltage:

3 x 230 Volt AC

Max. Frequency:

40 – 60 Hz – selectable

Min. Frequency:

0 - f-max

Electrical Efﬁ ciency:

> 95%

Protection against:

Short circuit, under-voltage, overheating of the electronics (overload) and

additional protective functions via external switch (motor temperature,

low

water).

A power supply ﬁ lter is included to ensure interference immunity.

The AV Series frequency converter complies with the general EMV provisions and has been tested
according to the following standards:

• Radio Interference Suppression EN 50081 Part 2 and EN 50082 Part 2
• High Frequency Field Interference ENV 50140 and ENV 50141
• Static Electricity Discharge EN 61000-4
• Disturbance Voltage EN55011

Ambient Temperature:

5° C – 40° C

Storage Temperature:

-25° C – +55° C

(+70° C during max. 24 hours)

Humidity:

rH maximum 50% at 40° C, unlimited

RH maximum 90% at 20° C, maximum 30 days per year

Condensation not permitted!

Air Pollution:

The air may contain dry dust as found in workshops where there is no

excessive quantity of dust due to machines. Excessive amounts of dust,

acids, corrosive gases, salts, etc. are not permitted.

Controller Enclosure:

NEMA 12, IP 55

Approvals:

UL, CUL, CE

Altitude:

Maximum 3000 feet above sea level. Consult factory for higher altitudes.
