Xylem IM122 R03 Watt-Knot Voltage Surge Arrestor (OBSOLETE) User Manual
Page 3
3
TROUBLESHOOTING
WIRING DIAGRAMS
Problem
Cause
Solution
1. Motor fails with Watt-Knot on
Watt-Knot improperly grounded.
Refer to grounding instructions.
system.
Motor failure unrelated to lightning
Replace motor.
or high voltage surge.
Watt-Knot connected improperly.
Refer to installation instructions.
Check all connections.
2. Motor overloads protector; fuses
Watt-Knot damaged by lightning or
Replace Watt-Knot
or circuit breakers will not hold.
extreme current surge.
TROUBLESHOOTING
WIRING DIAGRAMS
Not responsible for damage due to transient voltage surges.
Standard ITT Residential & Commercial product warranty applies to Watt-Knot.
NOTE: POWER COMPANY CONNECTIONS AT
TRANSFORMERS MUST BE KNOWN PRIOR
TO CONNECTING THREE PHASE RED JACKET
WATER PRODUCTS WATT-KNOTS.
