Xylem IM011 R05 Model ICS/ICS-F - Manual (Page 2)

2
Table of Contents
SUBJECT PAGE
Safety Instructions ......................................................... 3
Description and Specifications ....................................... 3
Installation – General .................................................... 3
Close Coupled Units ...................................................... 3
Frame Mounted Units ................................................... 3
Piping – General ............................................................ 4
Piping – Suction ............................................................ 4
Piping – Discharge ......................................................... 4
Wiring and Grounding .................................................. 4
Motor to Pump – Shaft Alignment ................................. 5
Operation ...................................................................... 5
Maintenance.................................................................. 5
Disassembly ................................................................... 5
Reassembly .................................................................... 6
Troubleshooting Guide .................................................. 6
Sectional Assembly ....................................................... 7
Parts List and Materials of Construction ........................ 7
Engineering Data ........................................................... 8
Goulds Water Technology Limited Warranty ............... 10
Owner’s Information
Model Number:
Serial Number:
Dealer:
Date of Purchase:
Date of Delivery:
