6. Connect the mains leads (L1, L2, L3, and earth (ground)) according to applicable cable
chart.
The earth (ground) conductor must be 50 mm ( 2.0 in.) longer than the phase
conductors in the junction box of the unit.
7. Make sure that the pump is correctly connected to earth (ground).
8. Make sure that any thermal contacts incorporated in the pump are properly connected
to the closed end splices.
9. Make sure that any thermal contacts incorporated in the pump are properly connected
to the terminal board.
10. Only applicable for standard version: Install the entry gland screw on the stator
housing.
11. Only applicable for Ex-version: Install the entry gland screw on the entrance cover.
Connect the motor cable to the starter and monitoring equipment
WARNING:
Do not install the starter equipment in an explosive zone unless it is explosion-proof rated.
NOTICE:
• Thermal contacts are incorporated in the pump.
• Thermal contacts must never be exposed to voltages higher than 250 V, breaking
current maximum 4 A. It is recommended that they are connected to 24 V over
separate fuses to protect other automatic equipment.
The single phase pumps must be equipped with a starter which has start and run
capacitors.
1. If thermal contacts are included in the pump installation, connect the T1 and T2 control
conductors to the monitoring equipment.
NOTICE:
Ex-approved products must always have the thermal contacts connected irrespective
of the ambient temperature.
2. Connect the mains leads (L1, L2, L3, and earth [ground]) to the starter equipment.
For information about the phase sequence and the color codes of the leads, see
3. Check the functionality of the monitoring equipment:
a) Check that the signals and the tripping function work properly.
b) Check that the relays, lamps, fuses, and connections are intact.
Replace any defective equipment.
Cable charts
Description
This topic contains general connection information. It also provides cable charts that show
connection alternatives for use with different cables and power supply.
Installation
GK, GV (8203, 8203X) Installation, Operation, and Maintenance Manual
21
