6

English

Getting Started

Connecting the Projector

Note: To ensure the projector works well with your computer,
please make sure the timing of the display mode is compatible
with the projector.

#

Description

#

Description

1

Power cord

6

Audio cable jack/jack

2

RS232 cable

7

Audio cable Jack/RCA

3

VGA cable

8

Composite video cable

4

HDMI cable

9

S-Video cable

5

3 RCA component cable

RS232

RS232

2

S-Video Output

VGA

Video Output

DVD player

DVD player,

Set-top Box,

HDTV receiver

Y

Y

D-Sub

D-Sub

R

W

HDMI

HDMI

RB

G

R

B

G

1

3

5

8

9

6

7

4
