Projector Overview

Projector Outlook

Front / upper side

Rear side

#

Description

#

Description

1

Ventilation (inlet)

6

Lens cap

2

Ventilation (outlet)

7

Power button

3

Remote control receivers

8

Remote control

4

Focus ring

9

Zoom lever

5

Zoom lens

10 Horn

#

Description

#

Description

1

Power socket

6

YPbPr input connector

2

Kensington

TM

lock port

7

S-Video input connector

3

RS232 connector

8

Composite video input connector

4

PC analog signal/HDTV/component video

input connector (VGA IN)

9

Audio input connector

5

HDMI connector

8

4

3

6

3

5

7

9

2

1

1

10

RS232

3

4

5

6

8 9

1

2

7
