Your Acer notebook tour - 13
Base view
2
3
1
4
5
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2
Ventilation and
cooling fan
Allows the computer to stay cool.
Do not cover or obstruct the
openings.
3 Speakers Deliver stereo audio output.
4
Memory
compartment Houses the computer's main
memory.
HDD compartment
Houses the computer's hard disk
drive memory.
5
Battery release
latch
Releases the battery for removal.
Insert a suitable tool and slide to
release.
5
Emergency eject
hole
Ejects the optical drive tray when
the computer is turned off.
Carefully insert a straightened
paper clip to eject the optical drive
tray.
6 DC-in jack Connects to an AC adapter.
