Hotpoint Ariston PFK 724X - Manual (Page 16)

EN
16
Overall view
Description of the
appliance
1. Upper rack
2. Upper sprayer arm
3. Tip-up compartments
4. Rack height adjuster
5. Lower rack
6. Lower sprayer arm
7. Cutlery basket
8. Washing filter
9. Salt dispenser
10. Detergent and rinse aid dispensers
11. Data plate
12. Control Panel
***
***
Only in completely built-in models.
*
Only available in selected models.
Control panel
The number and type of wash cycles and options may vary depending on the dishwasher model.
ON/OFF/RESET
button and
indicator light
Select wash
cycle knob
Low Salt
indicator light
*
Low Rinse aid
indicator light
*
Washing
indicator light
End
indicator light
Half load button
and indicator light
*
Delayed start button
and indicator light
*
Start/Pause button
and indicator light
Drying
indicator light
Good Night option
button and
indicator light
Time remaining
light-up display
Multi-functional tablets
button and indicator light
