Replaceable Parts
Troubleshooting
Problem Possible Solution
No picture • Make sure all connections are secure
• Make sure unit has power connected
• If power/CEC and input LEDS are blinking,
make sure that the HDMI outputs from the
sources are properly connected and engaged
No sound
• Make sure all connections are secure
• Make sure that HDMI outputs from the
sources have audio output engaged
CEC does not Function • Make sure that CEC function is activated on
the switch
• Make sure that CEC function is properly
activated on other equipment
Note: In order for CEC to work properly, every
component in the system must have CEC
capabilities
Specifications:
Inputs Outputs
Interface
40445: (4) HDMI Inputs
(3) Rear (1) Front
40446: (6) HDMI Inputs
(5) Rear (1) Front (1) HDMI output
Video Amplifier Bandwidth 2.25GHz
Power
DC OUTPUT 5V/1A Adaptor
100~240v 50~60Hz 0.2A
Weight
1 lb.
Dimensions (W x H x D) 8.75 x 2.75 x 1.25 in.
In the event of a lost or damaged part,
the following replaceable accessories are
available. Please call 877-AV-EXPERT
for order information.
• 98033-AC
Adapter
• 98031 Remote Control for 40445
• 98032 Remote Control for 40446
6
