Page 6

Text mode
Original mode

Step 5

Side View

Step 6

Step 6
Use a USB Cable to connect 5V DC power from PC to the USB A inlet on the side
of the 40698.

Step 6-1
Note: If 5VDC adapter is preferred. Connect included AC/DC adapter to “DC In” on
the back of 40698. Connect plug to 120VAC wall outlet.

Step 7
Push the Power keypad on the Main Unit or on the remote control.
Apply power to computer and display. Picture should now be visible.

Step7

Front View

Functions of buttons on the main unit:

1. POWER: On/off switch for this unit.
2. RESET: Press it to return to factory setting.
3. ZOOM: Press it to enlarge the picture on TV screen.
4.

Keys: Press the button to move the picture toward the direction of

arrows.
