Wireless network adapter User manual
Page 5 of 26
2.1 Cardbus adapter
Figure 1-1
LEDs
The two status LED indicators of the Cardbus wireless adapter are described in the following
figure and table.
LED Status
Description
PWR
ON (Green)
Indicates the Adapter is ready
ON (Green)
Indicates a valid connection
Lnk/Act
Flashing
Indicates the the Adapter is transmitting
or receiving data.
2.2 PCI adapter
Figure 1-2
LEDs
The Wireless PCI Adapter includes a status LED indicators, as described in the following table.
LED Status
Description
ON (Green)
Indicates a valid connection
Lnk/Act
Flashing
Indicates the the Adapter is transmitting
