3
Troubleshooting:
Specifications:
Inputs Outputs
Interface
1 DVI Female (DVI Local
Unit)
2 RJ-45 Port (DVI Remote
Unit) 1 DVI Female (DVI
Remote Unit)
2 RJ-45 Port (DVI Local
Unit)
Max Resolution 1600x1200 60Hz w/30 meter Cat5 cable/
1280x1024 60Hz w/60 meter Cat5 cable
Housing Material
Metal
Power DC 5V 1.2A
Weight .3 lbs.
Dimensions (L x W x H) 2.64 x 2.05 x 1.50 in.
Problem Possible Solution
No picture 1. Make sure to use Cat5e cables. Other category
cables may work, but results cannot be guaranteed
using other types.
2. Be sure that each unit is positioned correct. The
remote unit should connect to the display, and the
local unit should connect to your PC.
3. Check to see if the power indicator lights are on and
the units are plugged in.
