C2G 39971 TruLink VGA Switcher_Extender w_Audio User Manual
Page 5
2
Back of 39971
Operating the VGA Switcher/Extender
Operating the VGA Switcher/Extender with the remote control
1. To operate the switch by remote first remove the isolation mylar from the back of the remote
control.
2. Press 1 or 2 to select the input source of video and audio signal from
computers.
Operating the VGA Switcher/Extender from the front panel
1. Press Push Button to select the input source of Video and Audio signal from computers
connect
VGA port of Monitor or
Projector
DC 5V 1A Power Jack
VGA port (PC1)
VGA port (PC2)
Speaker output port
Please remove the Isolation Mylar.
