background image

The USB2.0 2-port manual share switch
User Manual

Specifications

Model

USB2.0 Manual Share Switch-2 Port

Ports

2 USB Type-B (to computer)

1 USB Type-A (to device or hub)

Power

Bus-powered 500mA per port

Push Button

Port selector

Status Lights

2 port-indicator LEDs

Storage Temperature

-10~85℃

Working Temperature

0~70℃

Hardware Installation

Just simply plug one USB cable into PC1 and “the USB2.0 2-port manual share

switch” USB type B port and another USB cable into PC2 and the other “the USB2.0

2-port manual share switch” USB type B port

1. Use one USB cable to connect PC1 and “the USB2.0 2-port manual share switch”

USB type B port, whose LED will blink couple times and keep light on, which

means PC1 has right to access the USB device.

2. Use another USB cable to connect PC2 and “the USB2.0 2-port manual share

switch” USB type B port. The LED of PC1 LED will blink couple times and keep

light on, which means PC2 is ready for hot key switch.

After connecting any USB device to our “the USB2.0 2-port manual share switch”,

you are ready to use the USB 2 port manual share switch either by press the switch

button on switch or double click the Scroll Lock button ( Hot Key ) on keyboard.








2
