Installation
1. Turn off the computer and monitor
2. Connect the HD-15 cable from your monitor to the “video out” port of the booster
3. Connect the power adapter to the booster and then to a wall outlet. The power
LED on the booster will light to indicate the booster is receiving power.
4. Turn on the computer and monitor
Daisy-Chaining Two Boosters
1. Turn off the computer and monitor
2. Connect the HD-15 cable from your monitor to the “video out” port of the first
booster
3. Connect a HD-15 video cable between the “video in” port of the first booster with
the “video out” port of another booster
4. Connect an HD-15 video cable (not included) between the “video output” of the
computer and the “video in” port of the second booster
5. Connect a power adapter to each booster and then to a wall outlet. The power
LED on the boosters will light to indicate the boosters are receiving power.
6. Turn on the computer and monitor
Note: Daisy-chaining boosters may cause a decline in image quality
Specifications
Function #29559 TruLink Video Signal Booster
Video Input Connector 1 x HD-15 Male
Video Output Connector 1 x HD-15 Female
Max. Resolution 1920 x 1440 @ 60Hz
Pixel Frequency 250 MHz
Cable Distance (Device to Monitor) 65 meters (213 ft) Max.
Signal Type VGA, SVGA, XGA, Multisync
Power Adapter 7.5V AC; 800mA
Housing Plastic
Weight 80
g
Dimensions (LxWxH) mm 97x56x26
Certifications FCC, CE, RoHS
