C2G 13138 TC-NT1 Network Cable Tester User Manual

Page 7

Caution:

1. Operating the tester in live circuits may damage the tester

2. Leaving the battery in the tester for long periods of time without use

could drain power from the battery

Test Results

1 2 3 4 5 6 7 8 G

1.Continuity:

Pin 2 has continuity

1 2 3 4 5 6 7 8 G

2.Open:

Pin 2 is opened

1 2 3 4 5 6 7 8 G

3.Short:

Pin 2 and Pin 3 are shorted

1 2 3 4 5 6 7 8 G

4.Miswire:

Pin 3 and Pin 6 are miswired
