UHF Wireless Systems User Manual
Specifications
Carrier type UHF 863 - 865MHz
Frequency stability ±0.005%
Maximum deviation ±25kHz
Audio frequency response 40Hz – 20kHz
Signal to noise ratio >105dB
Audio dynamic range >80dB
T.H.D. <0.5% @ 1kHz
Maximum range 50m
Operating temperature -10ºC to +50ºC
Receiver
Power supply 12 - 18Vdc 500mA (mains adapter supplied)
Audio outputs XLR (balanced), Jack (unbalanced)
Controls Power On/Off, Mic. Volume(s)
Indicators Power (main), RF and AF (for each channel)
Dimensions 45 x 210 x 180mm
Weight 573g
Handheld Transmitter (UH1, UH2, UHN2)
Battery 3Vdc (2 x AA)
Switch Power / Mute / On
RF emission >10mW
Capsule type Dynamic - cardioid response
Dimensions 242 x 45mmØ
Weight (without battery) 238g
Bodypack Transmitter (UN1, VN2, UHN2, UL1)
Battery 3Vdc (2 x AA)
Switch Power / Mute / On
Connector 3.5mm mono jack- threaded
Compatible microphones 171.855, 171.856, 171.857
RF emission >10mW
Dimensions (not inc. antenna) 110 x 68 x 25mm
Weight (without battery)
76g
Neckband Microphone (UN1, UN2, UHN2)
Capsule type Condenser - cardioid response
Power supply 3V phantom from bodypack
Connector 3.5mm mono jack - threaded
Dimensions 140 x 180 x 60mm
Weight 25g
Lavalier Microphone (UL1)
Capsule type Condenser - cardioid response
Power supply 3V phantom from bodypack
Connector 3.5mm mono jack- threaded
Dimensions 40 x 27 x 20mm
Weight 20g
