UHF Wireless Systems User Manual
Handheld Transmitter Bodypack Transmitter
Receiver Rear Panel
Receiver Front Panel
1. Windshield
2. Slide switch
– OFF/MUTE/ON
3. Battery compartment cover
1. Antennae
2. Power adapter input
3. Balanced XLR output
4. Unbalanced 6.3mm jack output
1. Power ON/OFF switch
2. Channel A volume control
3. Channel A Audio indicator LED
4. Channel A Radio signal LED
5. Power indicator LED
6. Channel B Radio signal LED
7. Channel B Audio indicator LED
8. Channel B volume control
1. UHF antenna
2. LED power indicator
3. Slide switch OFF/MUTE/ON
4. MIC input, threaded 3.5mm jack
5. Frequency label
6. GAIN ADJUST rotary
7. Battery compartment
