SmartLIGHT User Manual Page 11
SECONDARY FUNCTION:
A001-A512 DMX-512 Address from 1 to 512
Er_L
If there is a breakdown in the DMX connection
AUT1
Auto color switch
AUT2
Auto color switch , fade in & fade out effect
(slow fade in – slow fade out)
AUT3
WRGB Color Scroll, fade in & fade out (slow fade
in – quick fade out)
AUT4
Auto color mixing, Pastel scroll
SOU1
Sound Activated with colour changing mode
SOU2
Sound to light strobe all LEDs on. 3 flashes per
beat
SOU3
Sound to ligtht blast color switch quick fade in
slow fade out
MASTER/SLAVE:
If you have more than one unit you wish to operate the same but do not have a DMX
controller or foot controller then you can do so in the following simple way: Connect a 3 pin
DMX XLR cable from the DMX OUT socket on the master unit and plug in to the DMX IN socket
on the slave device. Then set the Slave device to DMX address to be A001 and it will repeat
whatever operation is current on the master unit. This can be repeated for up to 32 fixtures.
