Step 3:
Guide the screw on dipole box through the pre drilled holes on the main body arm, use the wing nut
supplied to tighten it in place.
Step 4:
Slide the reflectors into the housing and screw the housing onto the main body, please ensure the
narrower end of the reflector is heading inward and the wider end of the reflector is heading outward.
Step 5:
Install the support bracket on to the bottom boom arm by the two brackets supplied, please ensure the
shorter end is towards the tip of the antenna and the longer end is towards the reflectors
