INTRODUCTION:
Thank you for choosing Mercury antenna. This strong triple boom antenna is designed to pick up weak TV
signals where location is far away from the closest from the TV transmission tower. It is designed to be
easily assembled where most parts are secured with wing nuts. Please follow the steps below for
assembly.
Step 1:
Install the extensions on to the main body boom arm with supplied brackets and wing nuts as below.
Please ensure the longer extension goes to middle main beam and the two shorter extensions go on to
the upper and lower boom arm.
Step 2:
Install the boom arm joint and boom support as below, use a crosshead screw driver to tighten the 4
screws to lock in position.
