1. DESCRIpTION AND DATA
1.1 DESCRIpTION
The Armasight MCS (Miniature Collimating Sight) is a micro-LED collimat-
ing sight ideal for “both-eyes open”, rapid-target acquisition. The MCS is
rugged, lightweight, and is designed to mount onto many existing optics
as well as MIL-STD-1913 Picatinny and Weaver-style rails.
The Armasight MCS is the only sight in its class and on the market that fea-
tures a dual-reticle pattern. The user can select a 3.5 MOA “Dot” reticle or a 20
MOA “Ring” reticle pattern, depending on mission requirements. The MCS is
compatible with night vision devices of all generations. Reticle intensity is
regulated by an automatic brightness control sensor, which can be overrid-
den by the user and turned to maximum brightness mode if required.
The MCS is designed to significantly improve the accuracy and efficiency of
virtually any weapon, from handguns and pistols to assault rifles and light
machine guns. The compact size and versatility of the MCS make it an ideal
secondary or backup optical sight. Accurate and reliable, the Armasight
MCS features 1.2 MOA/click windage and 1.5 MOA/click adjustments. A
unique optical design allows for a parallax-free, “always on the center”
reticle.
The MCS is waterproof; it has been tested against salt fog, dust, and vibra-
tion. It has been drop-tested and mounted on a variety of firearms as they
fired thousands of rounds. The Armasight MCS complies with MIL-STD 810 G
standards. The MCS features a unique pivot lens cover that has anti-reflec-
tive coating, and it works on a single, easy to replace CR2032 3V battery.
1.2 KEY FEATURES
Tactile click stops for windage & elevation adjustments
–
A switchable 3.5 MOA dot to 20 MOA ring reticle pattern
–
Automatic brightness control of the reticle based on the target
–
area brightness
Rapid target acquisition
–
True night vision compatible mode
–
User configurable open or tube sight mode
–
Riflescope mounted or weaver mounted variations
–
Battery change with no change in zero
–
Large heads-up display with wide field of view
–
