Air Suspension A-2559 User Manual
Page 3
2002-2009 MERECEDES BENZ E-CLASS
(W211 CHASSIS) A-2536 / A-2559
REAR AIR SPRING REPLACEMENT
3
A-2536/A-2559
REV -
REAR SHOCK REMOVAL:
NOTE:
REAR AIR SPRING REMOVAL/INSTALLATION IS FOR BOTH THE
REAR RIGHT AND LEFT AIR SPRING.
The ignition must remain switched off during the shock removal and
replacement.
1.1 SET STEERING TO STRAIGHT AHEAD.
1.2 REMOVE POSITIVE BATTERY TERMINAL BEFORE STARTING WORK
Use lifting platform (hoist) that is capable of raising the body separately
from the wheels, lift body at the lifting points prescribed by the vehicle
manufacturer.
Vehicle slippage can cause danger to life and limb.
3.0 RAISE VEHICLE.
4.0
REMOVE REAR TIRE(S). (FIGURE 10-1)
FIGURE 10-1
