Air Suspension A-2559 User Manual
Page 2
2002-2009 MERECEDES BENZ E-CLASS
(W211 CHASSIS) A-2536 / A-2559
REAR AIR SPRING REPLACEMENT
2
A-2536/A-2559
REV -
WARNING:
The air suspension system is under pressure (up to 10 bar, or
150 lbf/in ) verify pressure has been relieved and disconnect power to the air ride
system prior to dis-assembly. Do not allow dirt or grease to enter the system.
Always wear standard protective hand, ear, and eye protection when servicing the
air suspension system.
Kit contains:
PARTS LIST
P/N
QTY
DESCRIPTION
A-2536/A-2559 2
REAR AIR SPRING
General information:
* Not to be stored below 5
0
F (-15
0
C) and above 122
0
F (50
0
C).
*Avoid damage to air lines and cables.
*Removal and installation is only to be performed by full qualified personnel.
*Use car manufacturer’s diagnostic software.*CAUTION: Damage to the vehicle
and shock assembly can be incurred if work is carried out in a manner other than
specified in the instructions or in a different sequence.
