Air Suspension A-2692 REV 1 User Manual
Page 3
3
A-
2692
ARNOTT REAR AIR SPRING
FOR
1995-2002
LAND ROVER RANGE ROVER (P
38
A CHASSIS)
REV 1
12/12/2013
A-2692
AIR SPRING INSTALLATION
1.
REMOVE SEAL FROM AIR HOSE. CONNECT THE HOSE TO THE AIR SPRING.
2.
AFFIX THE AIR SPRING TO THE CHASSIS. SECURE THE TOP OF THE AIR SPRING TO THE CHASSIS WITH THE
REMOVED CLIP.
3.
SLOWLY LOWER AIR SPRING ONTO THE AXLE. RE-SUPPORT THE CHASSIS.
4.
FIT THE CLIP TO SECURE BOTTOM OF THE AIR SPRING TO AXLE.
5.
INSTALLATION COMPLETE.
Tighten all nuts and bolts to manufacturer's specifications during the installation process.
