Air Suspension AS-2488 REV 2 User Manual
Page 5
5
REV 2
11/06/2013
AS-2488
AS-
2488
ARNOTT REMANUFACTURED REAR AIR STRUT
FOR
2004-2010
JAGUAR XJ
SERIES (COMFORT)
9.
REMOVE AIR STRUT. (FIGURE G)
10.
REMOVAL COMPLETE.
FIGURE H
FIGURE G
AIR STRUT INSTALLATION
1.
INSTALLATION IS IN REVERSE ORDER OF AIR STRUT REMOVAL.
Tighten all nuts and bolts to manufacturer's specifications during the installation process.
Do not remove the air fitting from the air strut. Doing so may cause damage and/or void warranty. Remove the white
shipping pin from the new air fitting and insert the air line until fully seated.
